Calcium Carbonate for White PVC Window Profiles
If white PVC profiles show colour variation or surface defects, the filler enquiry needs more than a powder-whiteness figure.
Relia's calcium carbonate candidates can be compared for particle distribution, treatment and moisture against your profile formulation.
- Profile colour
- Finished-part tolerance
- Coarse tail
- Distribution and residue data
- Surface
- Defect and dispersion record
From Your Requirement to a Defined Grade
Relia manufactures ground, precipitated and selected surface-coated calcium carbonate grades in China through its own factories.
Our carbonate range provides a starting point for your profile-material review. Tell Relia which colour reference, surface finish and impact requirements the finished profile must maintain. The grade discussion can then focus on the material variables behind those requirements, rather than treating every bright-looking powder as equivalent.
Profile colour
Finished-part tolerance
Coarse tail
Distribution and residue data
Powder condition
Treatment and moisture
Surface
Defect and dispersion record
The Finished Appearance
For a white PVC profile, a filler shortlist should preserve the colour target and extrusion window together. The 501 hard-plastic listing, the 40nm-designated powder and the 600–3000 mesh GCC range are three different starting proposals. We first narrow each range to an offered grade that can be sampled.
Finished-part tolerance
Distribution and residue data
Defect and dispersion record
Profile Grades with Distinct Starting Data
| Review area | Listed data and acceptance basis | Use in your selection |
|---|---|---|
| 501 · 6540 | Whiteness is listed at least 95%. Agree the instrument, reference and acceptable finished-profile colour. | Match the stated measurement method and compare the appearance in your finished material. |
| 40nm designation · 6527 | The title lists 98% whiteness. Ask what the 40nm designation measures and request the dispersed distribution. | Match the stated measurement method and compare the appearance in your finished material. |
| GCC range · 6538 | The listing covers 600–3000 mesh with 96% purity. Select one grade; the range is not one particle specification. | Use the same particle measurement basis, then review dispersion and the result in your process. |
| Extruded surface | Compare colour, specks, surface finish and mechanical acceptance in the same PVC formulation and processing window. | Match the stated measurement method and compare the appearance in your finished material. |
Compare the Product Candidates
Use these listed candidates to start a grade-specific discussion with us.
A Consistent Forming Trial
Keep resin, stabiliser and lubricant packages identified for the comparison. Follow extrusion conditions, surface appearance and relevant impact results on the same profile geometry. Fine primary particles can still arrive as agglomerates, so a nanometre designation should lead to a dispersion check rather than an automatic approval.
Whiteness
Powder colour is not finished-profile colour.
Nano wording
Verify measured particle data.
Repeat variation
Keep an approved reference.
Particle Preparation and Surface Condition
Mineral selection affects the colour background; milling and classification affect coarse particles; surface treatment affects dispersion in the PVC system. These variables can show up differently in powder measurements and in a finished profile. Retain both sets of results and the processing conditions when deciding whether a production grade is acceptable.
GCC: dry and wet routes
Relia uses both dry- and wet-grinding routes for GCC. Grinding and classification are connected to the selected powder's particle specification.
PCC: crystal formation
Relia produces PCC through calcination, slaking and carbonation. The precipitation route forms new particles rather than only grinding the starting mineral.
Selected surface-coated grades
Relia applies surface coating to selected carbonate grades. The actual treatment and intended application remain part of the grade discussion.
Defined carbonate checks
Routine batch checks cover whiteness, moisture and purity. Particle size and oil absorption are checked according to the grade or order requirements.
- Distribution
- Retain average size, D50 and D97 as their actual reported measurements.
- Surface
- Connect a treatment declaration with the application and absorption or wetting evidence.
- Identity
- Keep the selected grade and relevant method with the sample comparison.
A Colour Reference for Reorders
Retain the approved profile reference and its test conditions with the filler specification. We use those requirements when discussing the proposed supply grade. A change to the colour system, filler treatment or source gives both teams a clear reason to review again.
Continue Your Material Selection
If you make rigid PVC pipe, choose calcium carbonate around pipe performance and acceptable production cost.
If you produce PVC furniture edge banding, the filler must suit both the visible finish and the way the strip bends.
If calcium carbonate is being considered for PVC calendered film, begin with film thickness and the defects your line must avoid.
Start with Your Material Brief
Send us the details below to review a concrete grade proposal and the next evaluation step.
- Application and process
- Profile colour: Finished-part tolerance
- Material and grade
- Your current grade or one of the relevant product links above.
- Important requirements
- Coarse tail: Distribution and residue data; Surface: Defect and dispersion record
- Purchase scope
- Trial or order quantity, preferred package and destination.
